reuse consant from jit#49916
Closed
cccclai wants to merge 33 commits intogh/cccclai/13/basefrom
Closed
Conversation
[ghstack-poisoned]
Contributor
💊 CI failures summary and remediationsAs of commit 01db6a0 (more details on the Dr. CI page):
🕵️ 1 new failure recognized by patternsThe following CI failures do not appear to be due to upstream breakages:
|
[ghstack-poisoned]
[ghstack-poisoned]
[ghstack-poisoned]
[ghstack-poisoned]
[ghstack-poisoned]
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596) [ghstack-poisoned]
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596) [ghstack-poisoned]
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596) [ghstack-poisoned]
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596) [ghstack-poisoned]
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596) [ghstack-poisoned]
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596) [ghstack-poisoned]
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596) [ghstack-poisoned]
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596) [ghstack-poisoned]
Contributor
I'm not aware of 1. For 2 it's likely that there's constant propagation in jit to remove the constants. Maybe the same reason for 1. |
iseeyuan
approved these changes
Jan 7, 2021
## Summary
Jit will generate constant tensor value, and it locates in the constant folder after unzip model.ptl. Bytecode generated by lite interpreter also includes constant tensor, which are almost the same with the constant tensor value from jit. This pr reuses the constant tensor from jit. The implementation is:
1. In `export_module.cpp`, store all constant tensor value from jit in an `unordered_map constants_from_jit`, where the tensor value use tensor string as a hash. When writing bytecode (`writeByteCode` function), the map `constants_from_jit` will also be passed. If the constant in bytecode exist in `constants_from_jit`, it will be replaced by a tuple in this format `('tensor_jit_index', 4)`, where 4 is the index in tensor table from jit.
2. In `import.cpp`, it will also read from `constants` folder and loads the constant tensor. Then it scans the constants tensor from bytecode. If there exists tuple in this format `('tensor_jit_index', 4)` under `constants` fields, it will fetch the constant from the tensor table from jit and replace with it accordingly.
Previous `python -m torch.utils.show_pickle bytecode.pkl`
```
...
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '0', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '1', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '2', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
0.1,
1e-05,
None,
2,
1,
False,
...
)
...
```
Now `python -m torch.utils.show_pickle bytecode.pkl`
```
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
('tensor_jit_index', 4),
('tensor_jit_index', 3),
('tensor_jit_index', 2),
0.1,
1e-05,
None,
2,
1,
False,
0,
24,
True,
58,
('tensor_jit_index', 0),
3,
('tensor_jit_index', 1),
-1,
('tensor_jit_index', 12),
('tensor_jit_index', 11),
('tensor_jit_index', 10),
('tensor_jit_index', 9),
('tensor_jit_index', 8),
('tensor_jit_index', 7),
('tensor_jit_index', 6),
0.1,
1e-05,
None,
2,
1,
False,
)
...
```
## Test
1. Build pytorch locally. `MACOSX_DEPLOYMENT_TARGET=10.9 CC=clang CXX=clang++ USE_CUDA=0 DEBUG=1 MAX_JOBS=16 python setup.py develop`
2. Run `python save_lite.py`
```
import torch
# ~/Documents/pytorch/data/dog.jpg
model = torch.hub.load('pytorch/vision:v0.6.0', 'shufflenet_v2_x1_0', pretrained=True)
model.eval()
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
import pathlib
import tempfile
import torch.utils.mobile_optimizer
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
# move the input and model to GPU for speed if available
if torch.cuda.is_available():
input_batch = input_batch.to('cuda')
model.to('cuda')
with torch.no_grad():
output = model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output[0], dim=0))
traced = torch.jit.trace(model, input_batch)
sum(p.numel() * p.element_size() for p in traced.parameters())
tf = pathlib.Path('~/Documents/pytorch/data/data/example_debug_map_with_tensorkey.ptl')
torch.jit.save(traced, tf.name)
print(pathlib.Path(tf.name).stat().st_size)
traced._save_for_lite_interpreter(tf.name)
print(pathlib.Path(tf.name).stat().st_size)
print(tf.name)
```
3. Run `python test_lite.py`
```
import torch
from torch.jit.mobile import _load_for_lite_interpreter
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
reload_lite_model = _load_for_lite_interpreter('~/Documents/pytorch/experiment/example_debug_map_with_tensorkey.ptl')
with torch.no_grad():
output_lite = reload_lite_model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output_lite[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output_lite[0], dim=0))
```
4. Compare the result with pytorch in master and pytorch built locally with this change, and see the same output.
5. The model size was 16.1 MB and becomes 12.9 with this change.
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596)
[ghstack-poisoned]
kimishpatel
reviewed
Jan 7, 2021
| const Function& func, | ||
| bool save_mobile_debug_info) { | ||
| const std:: | ||
| unordered_map<at::Tensor, int, tensor_value_hash, tensor_value_equal>& |
Contributor
There was a problem hiding this comment.
Do we need to create hash by converting tensor to string? Can we not use underlying storage ptr? I dont know if we have aliasing in constant where two constant tensors might refer to the same underlying memory but we can safeguard against that by using tensor sizes on top of storage ptr.
Contributor
Author
There was a problem hiding this comment.
Hmm I don't think I use hash with ptr. The customized hash tensor_value_hash is using string and comes from here (https://github.com/pytorch/pytorch/blob/master/aten/src/ATen/core/Formatting.cpp#L230). Here is one example:
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '0', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict())
Do I misunderstand anything?
Contributor
Author
There was a problem hiding this comment.
@kimishpatel do you have any other concern for this change?
Contributor
There was a problem hiding this comment.
Sorry on PTO today. What I meant to say is: Why are we converting tensor to str and using that as hash?
What are the other options? Can we not just do std::hash<void*>(tensor.data_ptr())? or mix tensor.data_ptr() with tensor.sizes()? Stringifying tensor for hashing seems like overkill.
Contributor
Author
There was a problem hiding this comment.
Oops sorry. I didn't notice you are on PTO today. It's actually intended to use string as the hash. The reason is that the key of constants_from_jit is tensor, and it's from the constants from jit, which has different ptr than the constants from mobile. I used the IValue hash function at the beginning, which uses ptr as hash for tensor type under the hood, instead of this customized hash function. It didn't work so I switched to string as hash input.
Side note: IValue hash function is defined here (https://github.com/pytorch/pytorch/blob/master/aten/src/ATen/core/ivalue.cpp#L323-L334). For tensor type, ptr is part of the hash input.
kimishpatel
approved these changes
Jan 8, 2021
## Summary
Jit will generate constant tensor value, and it locates in the constant folder after unzip model.ptl. Bytecode generated by lite interpreter also includes constant tensor, which are almost the same with the constant tensor value from jit. This pr reuses the constant tensor from jit. The implementation is:
1. In `export_module.cpp`, store all constant tensor value from jit in an `unordered_map constants_from_jit`, where the tensor value use tensor string as a hash. When writing bytecode (`writeByteCode` function), the map `constants_from_jit` will also be passed. If the constant in bytecode exist in `constants_from_jit`, it will be replaced by a tuple in this format `('tensor_jit_index', 4)`, where 4 is the index in tensor table from jit.
2. In `import.cpp`, it will also read from `constants` folder and loads the constant tensor. Then it scans the constants tensor from bytecode. If there exists tuple in this format `('tensor_jit_index', 4)` under `constants` fields, it will fetch the constant from the tensor table from jit and replace with it accordingly.
Previous `python -m torch.utils.show_pickle bytecode.pkl`
```
...
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '0', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '1', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '2', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
0.1,
1e-05,
None,
2,
1,
False,
...
)
...
```
Now `python -m torch.utils.show_pickle bytecode.pkl`
```
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
('tensor_jit_index', 4),
('tensor_jit_index', 3),
('tensor_jit_index', 2),
0.1,
1e-05,
None,
2,
1,
False,
0,
24,
True,
58,
('tensor_jit_index', 0),
3,
('tensor_jit_index', 1),
-1,
('tensor_jit_index', 12),
('tensor_jit_index', 11),
('tensor_jit_index', 10),
('tensor_jit_index', 9),
('tensor_jit_index', 8),
('tensor_jit_index', 7),
('tensor_jit_index', 6),
0.1,
1e-05,
None,
2,
1,
False,
)
...
```
## Test
1. Build pytorch locally. `MACOSX_DEPLOYMENT_TARGET=10.9 CC=clang CXX=clang++ USE_CUDA=0 DEBUG=1 MAX_JOBS=16 python setup.py develop`
2. Run `python save_lite.py`
```
import torch
# ~/Documents/pytorch/data/dog.jpg
model = torch.hub.load('pytorch/vision:v0.6.0', 'shufflenet_v2_x1_0', pretrained=True)
model.eval()
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
import pathlib
import tempfile
import torch.utils.mobile_optimizer
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
# move the input and model to GPU for speed if available
if torch.cuda.is_available():
input_batch = input_batch.to('cuda')
model.to('cuda')
with torch.no_grad():
output = model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output[0], dim=0))
traced = torch.jit.trace(model, input_batch)
sum(p.numel() * p.element_size() for p in traced.parameters())
tf = pathlib.Path('~/Documents/pytorch/data/data/example_debug_map_with_tensorkey.ptl')
torch.jit.save(traced, tf.name)
print(pathlib.Path(tf.name).stat().st_size)
traced._save_for_lite_interpreter(tf.name)
print(pathlib.Path(tf.name).stat().st_size)
print(tf.name)
```
3. Run `python test_lite.py`
```
import torch
from torch.jit.mobile import _load_for_lite_interpreter
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
reload_lite_model = _load_for_lite_interpreter('~/Documents/pytorch/experiment/example_debug_map_with_tensorkey.ptl')
with torch.no_grad():
output_lite = reload_lite_model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output_lite[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output_lite[0], dim=0))
```
4. Compare the result with pytorch in master and pytorch built locally with this change, and see the same output.
5. The model size was 16.1 MB and becomes 12.9 with this change.
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596)
[ghstack-poisoned]
## Summary
Jit will generate constant tensor value, and it locates in the constant folder after unzip model.ptl. Bytecode generated by lite interpreter also includes constant tensor, which are almost the same with the constant tensor value from jit. This pr reuses the constant tensor from jit. The implementation is:
1. In `export_module.cpp`, store all constant tensor value from jit in an `unordered_map constants_from_jit`, where the tensor value use tensor string as a hash. When writing bytecode (`writeByteCode` function), the map `constants_from_jit` will also be passed. If the constant in bytecode exist in `constants_from_jit`, it will be replaced by a tuple in this format `('tensor_jit_index', 4)`, where 4 is the index in tensor table from jit.
2. In `import.cpp`, it will also read from `constants` folder and loads the constant tensor. Then it scans the constants tensor from bytecode. If there exists tuple in this format `('tensor_jit_index', 4)` under `constants` fields, it will fetch the constant from the tensor table from jit and replace with it accordingly.
Previous `python -m torch.utils.show_pickle bytecode.pkl`
```
...
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '0', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '1', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '2', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
0.1,
1e-05,
None,
2,
1,
False,
...
)
...
```
Now `python -m torch.utils.show_pickle bytecode.pkl`
```
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
('tensor_jit_index', 4),
('tensor_jit_index', 3),
('tensor_jit_index', 2),
0.1,
1e-05,
None,
2,
1,
False,
0,
24,
True,
58,
('tensor_jit_index', 0),
3,
('tensor_jit_index', 1),
-1,
('tensor_jit_index', 12),
('tensor_jit_index', 11),
('tensor_jit_index', 10),
('tensor_jit_index', 9),
('tensor_jit_index', 8),
('tensor_jit_index', 7),
('tensor_jit_index', 6),
0.1,
1e-05,
None,
2,
1,
False,
)
...
```
## Test
1. Build pytorch locally. `MACOSX_DEPLOYMENT_TARGET=10.9 CC=clang CXX=clang++ USE_CUDA=0 DEBUG=1 MAX_JOBS=16 python setup.py develop`
2. Run `python save_lite.py`
```
import torch
# ~/Documents/pytorch/data/dog.jpg
model = torch.hub.load('pytorch/vision:v0.6.0', 'shufflenet_v2_x1_0', pretrained=True)
model.eval()
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
import pathlib
import tempfile
import torch.utils.mobile_optimizer
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
# move the input and model to GPU for speed if available
if torch.cuda.is_available():
input_batch = input_batch.to('cuda')
model.to('cuda')
with torch.no_grad():
output = model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output[0], dim=0))
traced = torch.jit.trace(model, input_batch)
sum(p.numel() * p.element_size() for p in traced.parameters())
tf = pathlib.Path('~/Documents/pytorch/data/data/example_debug_map_with_tensorkey.ptl')
torch.jit.save(traced, tf.name)
print(pathlib.Path(tf.name).stat().st_size)
traced._save_for_lite_interpreter(tf.name)
print(pathlib.Path(tf.name).stat().st_size)
print(tf.name)
```
3. Run `python test_lite.py`
```
import torch
from torch.jit.mobile import _load_for_lite_interpreter
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
reload_lite_model = _load_for_lite_interpreter('~/Documents/pytorch/experiment/example_debug_map_with_tensorkey.ptl')
with torch.no_grad():
output_lite = reload_lite_model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output_lite[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output_lite[0], dim=0))
```
4. Compare the result with pytorch in master and pytorch built locally with this change, and see the same output.
5. The model size was 16.1 MB and becomes 12.9 with this change.
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596)
[ghstack-poisoned]
## Summary
Jit will generate constant tensor value, and it locates in the constant folder after unzip model.ptl. Bytecode generated by lite interpreter also includes constant tensor, which are almost the same with the constant tensor value from jit. This pr reuses the constant tensor from jit. The implementation is:
1. In `export_module.cpp`, store all constant tensor value from jit in an `unordered_map constants_from_jit`, where the tensor value use tensor string as a hash. When writing bytecode (`writeByteCode` function), the map `constants_from_jit` will also be passed. If the constant in bytecode exist in `constants_from_jit`, it will be replaced by a tuple in this format `('tensor_jit_index', 4)`, where 4 is the index in tensor table from jit.
2. In `import.cpp`, it will also read from `constants` folder and loads the constant tensor. Then it scans the constants tensor from bytecode. If there exists tuple in this format `('tensor_jit_index', 4)` under `constants` fields, it will fetch the constant from the tensor table from jit and replace with it accordingly.
Previous `python -m torch.utils.show_pickle bytecode.pkl`
```
...
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '0', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '1', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '2', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
0.1,
1e-05,
None,
2,
1,
False,
...
)
...
```
Now `python -m torch.utils.show_pickle bytecode.pkl`
```
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
('tensor_jit_index', 4),
('tensor_jit_index', 3),
('tensor_jit_index', 2),
0.1,
1e-05,
None,
2,
1,
False,
0,
24,
True,
58,
('tensor_jit_index', 0),
3,
('tensor_jit_index', 1),
-1,
('tensor_jit_index', 12),
('tensor_jit_index', 11),
('tensor_jit_index', 10),
('tensor_jit_index', 9),
('tensor_jit_index', 8),
('tensor_jit_index', 7),
('tensor_jit_index', 6),
0.1,
1e-05,
None,
2,
1,
False,
)
...
```
## Test
1. Build pytorch locally. `MACOSX_DEPLOYMENT_TARGET=10.9 CC=clang CXX=clang++ USE_CUDA=0 DEBUG=1 MAX_JOBS=16 python setup.py develop`
2. Run `python save_lite.py`
```
import torch
# ~/Documents/pytorch/data/dog.jpg
model = torch.hub.load('pytorch/vision:v0.6.0', 'shufflenet_v2_x1_0', pretrained=True)
model.eval()
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
import pathlib
import tempfile
import torch.utils.mobile_optimizer
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
# move the input and model to GPU for speed if available
if torch.cuda.is_available():
input_batch = input_batch.to('cuda')
model.to('cuda')
with torch.no_grad():
output = model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output[0], dim=0))
traced = torch.jit.trace(model, input_batch)
sum(p.numel() * p.element_size() for p in traced.parameters())
tf = pathlib.Path('~/Documents/pytorch/data/data/example_debug_map_with_tensorkey.ptl')
torch.jit.save(traced, tf.name)
print(pathlib.Path(tf.name).stat().st_size)
traced._save_for_lite_interpreter(tf.name)
print(pathlib.Path(tf.name).stat().st_size)
print(tf.name)
```
3. Run `python test_lite.py`
```
import torch
from torch.jit.mobile import _load_for_lite_interpreter
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
reload_lite_model = _load_for_lite_interpreter('~/Documents/pytorch/experiment/example_debug_map_with_tensorkey.ptl')
with torch.no_grad():
output_lite = reload_lite_model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output_lite[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output_lite[0], dim=0))
```
4. Compare the result with pytorch in master and pytorch built locally with this change, and see the same output.
5. The model size was 16.1 MB and becomes 12.9 with this change.
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596)
[ghstack-poisoned]
## Summary
Jit will generate constant tensor value, and it locates in the constant folder after unzip model.ptl. Bytecode generated by lite interpreter also includes constant tensor, which are almost the same with the constant tensor value from jit. This pr reuses the constant tensor from jit. The implementation is:
1. In `export_module.cpp`, store all constant tensor value from jit in an `unordered_map constants_from_jit`, where the tensor value use tensor string as a hash. When writing bytecode (`writeByteCode` function), the map `constants_from_jit` will also be passed. If the constant in bytecode exist in `constants_from_jit`, it will be replaced by a tuple in this format `('tensor_jit_index', 4)`, where 4 is the index in tensor table from jit.
2. In `import.cpp`, it will also read from `constants` folder and loads the constant tensor. Then it scans the constants tensor from bytecode. If there exists tuple in this format `('tensor_jit_index', 4)` under `constants` fields, it will fetch the constant from the tensor table from jit and replace with it accordingly.
Previous `python -m torch.utils.show_pickle bytecode.pkl`
```
...
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '0', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '1', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '2', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
0.1,
1e-05,
None,
2,
1,
False,
...
)
...
```
Now `python -m torch.utils.show_pickle bytecode.pkl`
```
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
('tensor_jit_index', 4),
('tensor_jit_index', 3),
('tensor_jit_index', 2),
0.1,
1e-05,
None,
2,
1,
False,
0,
24,
True,
58,
('tensor_jit_index', 0),
3,
('tensor_jit_index', 1),
-1,
('tensor_jit_index', 12),
('tensor_jit_index', 11),
('tensor_jit_index', 10),
('tensor_jit_index', 9),
('tensor_jit_index', 8),
('tensor_jit_index', 7),
('tensor_jit_index', 6),
0.1,
1e-05,
None,
2,
1,
False,
)
...
```
## Test
1. Build pytorch locally. `MACOSX_DEPLOYMENT_TARGET=10.9 CC=clang CXX=clang++ USE_CUDA=0 DEBUG=1 MAX_JOBS=16 python setup.py develop`
2. Run `python save_lite.py`
```
import torch
# ~/Documents/pytorch/data/dog.jpg
model = torch.hub.load('pytorch/vision:v0.6.0', 'shufflenet_v2_x1_0', pretrained=True)
model.eval()
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
import pathlib
import tempfile
import torch.utils.mobile_optimizer
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
# move the input and model to GPU for speed if available
if torch.cuda.is_available():
input_batch = input_batch.to('cuda')
model.to('cuda')
with torch.no_grad():
output = model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output[0], dim=0))
traced = torch.jit.trace(model, input_batch)
sum(p.numel() * p.element_size() for p in traced.parameters())
tf = pathlib.Path('~/Documents/pytorch/data/data/example_debug_map_with_tensorkey.ptl')
torch.jit.save(traced, tf.name)
print(pathlib.Path(tf.name).stat().st_size)
traced._save_for_lite_interpreter(tf.name)
print(pathlib.Path(tf.name).stat().st_size)
print(tf.name)
```
3. Run `python test_lite.py`
```
import torch
from torch.jit.mobile import _load_for_lite_interpreter
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
reload_lite_model = _load_for_lite_interpreter('~/Documents/pytorch/experiment/example_debug_map_with_tensorkey.ptl')
with torch.no_grad():
output_lite = reload_lite_model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output_lite[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output_lite[0], dim=0))
```
4. Compare the result with pytorch in master and pytorch built locally with this change, and see the same output.
5. The model size was 16.1 MB and becomes 12.9 with this change.
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596)
[ghstack-poisoned]
## Summary
Jit will generate constant tensor value, and it locates in the constant folder after unzip model.ptl. Bytecode generated by lite interpreter also includes constant tensor, which are almost the same with the constant tensor value from jit. This pr reuses the constant tensor from jit. The implementation is:
1. In `export_module.cpp`, store all constant tensor value from jit in an `unordered_map constants_from_jit`, where the tensor value use tensor string as a hash. When writing bytecode (`writeByteCode` function), the map `constants_from_jit` will also be passed. If the constant in bytecode exist in `constants_from_jit`, it will be replaced by a tuple in this format `('tensor_jit_index', 4)`, where 4 is the index in tensor table from jit.
2. In `import.cpp`, it will also read from `constants` folder and loads the constant tensor. Then it scans the constants tensor from bytecode. If there exists tuple in this format `('tensor_jit_index', 4)` under `constants` fields, it will fetch the constant from the tensor table from jit and replace with it accordingly.
Previous `python -m torch.utils.show_pickle bytecode.pkl`
```
...
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '0', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '1', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '2', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
0.1,
1e-05,
None,
2,
1,
False,
...
)
...
```
Now `python -m torch.utils.show_pickle bytecode.pkl`
```
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
('tensor_jit_index', 4),
('tensor_jit_index', 3),
('tensor_jit_index', 2),
0.1,
1e-05,
None,
2,
1,
False,
0,
24,
True,
58,
('tensor_jit_index', 0),
3,
('tensor_jit_index', 1),
-1,
('tensor_jit_index', 12),
('tensor_jit_index', 11),
('tensor_jit_index', 10),
('tensor_jit_index', 9),
('tensor_jit_index', 8),
('tensor_jit_index', 7),
('tensor_jit_index', 6),
0.1,
1e-05,
None,
2,
1,
False,
)
...
```
## Test
1. Build pytorch locally. `MACOSX_DEPLOYMENT_TARGET=10.9 CC=clang CXX=clang++ USE_CUDA=0 DEBUG=1 MAX_JOBS=16 python setup.py develop`
2. Run `python save_lite.py`
```
import torch
# ~/Documents/pytorch/data/dog.jpg
model = torch.hub.load('pytorch/vision:v0.6.0', 'shufflenet_v2_x1_0', pretrained=True)
model.eval()
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
import pathlib
import tempfile
import torch.utils.mobile_optimizer
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
# move the input and model to GPU for speed if available
if torch.cuda.is_available():
input_batch = input_batch.to('cuda')
model.to('cuda')
with torch.no_grad():
output = model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output[0], dim=0))
traced = torch.jit.trace(model, input_batch)
sum(p.numel() * p.element_size() for p in traced.parameters())
tf = pathlib.Path('~/Documents/pytorch/data/data/example_debug_map_with_tensorkey.ptl')
torch.jit.save(traced, tf.name)
print(pathlib.Path(tf.name).stat().st_size)
traced._save_for_lite_interpreter(tf.name)
print(pathlib.Path(tf.name).stat().st_size)
print(tf.name)
```
3. Run `python test_lite.py`
```
import torch
from torch.jit.mobile import _load_for_lite_interpreter
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
reload_lite_model = _load_for_lite_interpreter('~/Documents/pytorch/experiment/example_debug_map_with_tensorkey.ptl')
with torch.no_grad():
output_lite = reload_lite_model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output_lite[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output_lite[0], dim=0))
```
4. Compare the result with pytorch in master and pytorch built locally with this change, and see the same output.
5. The model size was 16.1 MB and becomes 12.9 with this change.
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596)
[ghstack-poisoned]
## Summary
Jit will generate constant tensor value, and it locates in the constant folder after unzip model.ptl. Bytecode generated by lite interpreter also includes constant tensor, which are almost the same with the constant tensor value from jit. This pr reuses the constant tensor from jit. The implementation is:
1. In `export_module.cpp`, store all constant tensor value from jit in an `unordered_map constants_from_jit`, where the tensor value use tensor string as a hash. When writing bytecode (`writeByteCode` function), the map `constants_from_jit` will also be passed. If the constant in bytecode exist in `constants_from_jit`, it will be replaced by a tuple in this format `('tensor_jit_index', 4)`, where 4 is the index in tensor table from jit.
2. In `import.cpp`, it will also read from `constants` folder and loads the constant tensor. Then it scans the constants tensor from bytecode. If there exists tuple in this format `('tensor_jit_index', 4)` under `constants` fields, it will fetch the constant from the tensor table from jit and replace with it accordingly.
Previous `python -m torch.utils.show_pickle bytecode.pkl`
```
...
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '0', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '1', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '2', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
0.1,
1e-05,
None,
2,
1,
False,
...
)
...
```
Now `python -m torch.utils.show_pickle bytecode.pkl`
```
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
('tensor_jit_index', 4),
('tensor_jit_index', 3),
('tensor_jit_index', 2),
0.1,
1e-05,
None,
2,
1,
False,
0,
24,
True,
58,
('tensor_jit_index', 0),
3,
('tensor_jit_index', 1),
-1,
('tensor_jit_index', 12),
('tensor_jit_index', 11),
('tensor_jit_index', 10),
('tensor_jit_index', 9),
('tensor_jit_index', 8),
('tensor_jit_index', 7),
('tensor_jit_index', 6),
0.1,
1e-05,
None,
2,
1,
False,
)
...
```
## Test
1. Build pytorch locally. `MACOSX_DEPLOYMENT_TARGET=10.9 CC=clang CXX=clang++ USE_CUDA=0 DEBUG=1 MAX_JOBS=16 python setup.py develop`
2. Run `python save_lite.py`
```
import torch
# ~/Documents/pytorch/data/dog.jpg
model = torch.hub.load('pytorch/vision:v0.6.0', 'shufflenet_v2_x1_0', pretrained=True)
model.eval()
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
import pathlib
import tempfile
import torch.utils.mobile_optimizer
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
# move the input and model to GPU for speed if available
if torch.cuda.is_available():
input_batch = input_batch.to('cuda')
model.to('cuda')
with torch.no_grad():
output = model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output[0], dim=0))
traced = torch.jit.trace(model, input_batch)
sum(p.numel() * p.element_size() for p in traced.parameters())
tf = pathlib.Path('~/Documents/pytorch/data/data/example_debug_map_with_tensorkey.ptl')
torch.jit.save(traced, tf.name)
print(pathlib.Path(tf.name).stat().st_size)
traced._save_for_lite_interpreter(tf.name)
print(pathlib.Path(tf.name).stat().st_size)
print(tf.name)
```
3. Run `python test_lite.py`
```
import torch
from torch.jit.mobile import _load_for_lite_interpreter
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
reload_lite_model = _load_for_lite_interpreter('~/Documents/pytorch/experiment/example_debug_map_with_tensorkey.ptl')
with torch.no_grad():
output_lite = reload_lite_model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output_lite[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output_lite[0], dim=0))
```
4. Compare the result with pytorch in master and pytorch built locally with this change, and see the same output.
5. The model size was 16.1 MB and becomes 12.9 with this change.
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596)
[ghstack-poisoned]
## Summary
Jit will generate constant tensor value, and it locates in the constant folder after unzip model.ptl. Bytecode generated by lite interpreter also includes constant tensor, which are almost the same with the constant tensor value from jit. This pr reuses the constant tensor from jit. The implementation is:
1. In `export_module.cpp`, store all constant tensor value from jit in an `unordered_map constants_from_jit`, where the tensor value use tensor string as a hash. When writing bytecode (`writeByteCode` function), the map `constants_from_jit` will also be passed. If the constant in bytecode exist in `constants_from_jit`, it will be replaced by a tuple in this format `('tensor_jit_index', 4)`, where 4 is the index in tensor table from jit.
2. In `import.cpp`, it will also read from `constants` folder and loads the constant tensor. Then it scans the constants tensor from bytecode. If there exists tuple in this format `('tensor_jit_index', 4)` under `constants` fields, it will fetch the constant from the tensor table from jit and replace with it accordingly.
Previous `python -m torch.utils.show_pickle bytecode.pkl`
```
...
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '0', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '1', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '2', 'cpu', 90944),),
0,
(1, 116, 28, 28),
(90944, 784, 28, 1),
False,
collections.OrderedDict()),
0.1,
1e-05,
None,
2,
1,
False,
...
)
...
```
Now `python -m torch.utils.show_pickle bytecode.pkl`
```
('constants',
(0.1,
1e-05,
None,
2,
1,
False,
0,
True,
False,
1,
2,
3,
('tensor_jit_index', 4),
('tensor_jit_index', 3),
('tensor_jit_index', 2),
0.1,
1e-05,
None,
2,
1,
False,
0,
24,
True,
58,
('tensor_jit_index', 0),
3,
('tensor_jit_index', 1),
-1,
('tensor_jit_index', 12),
('tensor_jit_index', 11),
('tensor_jit_index', 10),
('tensor_jit_index', 9),
('tensor_jit_index', 8),
('tensor_jit_index', 7),
('tensor_jit_index', 6),
0.1,
1e-05,
None,
2,
1,
False,
)
...
```
## Test
1. Build pytorch locally. `MACOSX_DEPLOYMENT_TARGET=10.9 CC=clang CXX=clang++ USE_CUDA=0 DEBUG=1 MAX_JOBS=16 python setup.py develop`
2. Run `python save_lite.py`
```
import torch
# ~/Documents/pytorch/data/dog.jpg
model = torch.hub.load('pytorch/vision:v0.6.0', 'shufflenet_v2_x1_0', pretrained=True)
model.eval()
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
import pathlib
import tempfile
import torch.utils.mobile_optimizer
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
# move the input and model to GPU for speed if available
if torch.cuda.is_available():
input_batch = input_batch.to('cuda')
model.to('cuda')
with torch.no_grad():
output = model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output[0], dim=0))
traced = torch.jit.trace(model, input_batch)
sum(p.numel() * p.element_size() for p in traced.parameters())
tf = pathlib.Path('~/Documents/pytorch/data/data/example_debug_map_with_tensorkey.ptl')
torch.jit.save(traced, tf.name)
print(pathlib.Path(tf.name).stat().st_size)
traced._save_for_lite_interpreter(tf.name)
print(pathlib.Path(tf.name).stat().st_size)
print(tf.name)
```
3. Run `python test_lite.py`
```
import torch
from torch.jit.mobile import _load_for_lite_interpreter
# sample execution (requires torchvision)
from PIL import Image
from torchvision import transforms
input_image = Image.open('~/Documents/pytorch/data/dog.jpg')
preprocess = transforms.Compose([
transforms.Resize(256),
transforms.CenterCrop(224),
transforms.ToTensor(),
transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]),
])
input_tensor = preprocess(input_image)
input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model
reload_lite_model = _load_for_lite_interpreter('~/Documents/pytorch/experiment/example_debug_map_with_tensorkey.ptl')
with torch.no_grad():
output_lite = reload_lite_model(input_batch)
# Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes
print(output_lite[0])
# The output has unnormalized scores. To get probabilities, you can run a softmax on it.
print(torch.nn.functional.softmax(output_lite[0], dim=0))
```
4. Compare the result with pytorch in master and pytorch built locally with this change, and see the same output.
5. The model size was 16.1 MB and becomes 12.9 with this change.
Differential Revision: [D25731596](https://our.internmc.facebook.com/intern/diff/D25731596)
[ghstack-poisoned]
Contributor
Contributor
|
This pull request has been reverted by e05882d. |
cccclai
added a commit
that referenced
this pull request
Jan 22, 2021
## Summary This change is originally introduce in #49916, however, it ran into issue for one model and reverted in #50521. This pr re-enable reusing constant from jit with the change to fix. The issue is in the last else statement. It shouldn't be an else statement, but to catch all cases when any if statement fails. The correct code should remove the else, and add a continue when the current `const_item` meets all criterias and push to `updated_constant_vals`. It's a bit tricky to debug this problem, since the code is running in different threads and sometimes breaks at unrelated place. Before: ``` std::vector<IValue> updated_constant_vals; for (const auto& const_item : consts_list) { if (const_item.isTuple()) { const auto& tensor_jit = const_item.toTuple()->elements(); if (tensor_jit.size() > 1) { const auto& tensor_jit_index_key = tensor_jit[0]; const auto& tensor_jit_index = tensor_jit[1]; if (tensor_jit_index_key.isString() && tensor_jit_index_key.toString().get()->string() == mobile::kTensorJitIndex) { updated_constant_vals.push_back( constant_vals_from_jit[tensor_jit_index.toInt()]); } } } else { updated_constant_vals.push_back(const_item); } } ``` Current: ``` for (const auto& const_item : consts_list) { if (const_item.isTuple()) { const auto& tensor_jit = const_item.toTuple()->elements(); if (tensor_jit.size() > 1) { const auto& tensor_jit_index_key = tensor_jit[0]; const auto& tensor_jit_index = tensor_jit[1]; if (tensor_jit_index_key.isString() && tensor_jit_index_key.toString().get()->string() == mobile::kTensorJitIndex) { updated_constant_vals.push_back( constant_vals_from_jit[tensor_jit_index.toInt()]); continue; } } } updated_constant_vals.push_back(const_item); } ``` ## Test plan In addition to run the test in #49916, 1. Run PyTorchPlayGroundMac  2. `buck test pp-macos` ### Copy the summary and test plan in #49916 here ## Summary Jit will generate constant tensor value, and it locates in the constant folder after unzip model.ptl. Bytecode generated by lite interpreter also includes constant tensor, which are almost the same with the constant tensor value from jit. This pr reuses the constant tensor from jit. The implementation is: 1. In `export_module.cpp`, store all constant tensor value from jit in an `unordered_map constants_from_jit`, where the tensor value use tensor string as a hash. When writing bytecode (`writeByteCode` function), the map `constants_from_jit` will also be passed. If the constant in bytecode exist in `constants_from_jit`, it will be replaced by a tuple in this format `('tensor_jit_index', 4)`, where 4 is the index in tensor table from jit. 2. In `import.cpp`, it will also read from `constants` folder and loads the constant tensor. Then it scans the constants tensor from bytecode. If there exists tuple in this format `('tensor_jit_index', 4)` under `constants` fields, it will fetch the constant from the tensor table from jit and replace with it accordingly. Previous `python -m torch.utils.show_pickle bytecode.pkl` ``` ... ('constants', (0.1, 1e-05, None, 2, 1, False, 0, True, False, 1, 2, 3, torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '0', 'cpu', 90944),), 0, (1, 116, 28, 28), (90944, 784, 28, 1), False, collections.OrderedDict()), torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '1', 'cpu', 90944),), 0, (1, 116, 28, 28), (90944, 784, 28, 1), False, collections.OrderedDict()), torch._utils._rebuild_tensor_v2(pers.obj(('storage', torch.FloatStorage, '2', 'cpu', 90944),), 0, (1, 116, 28, 28), (90944, 784, 28, 1), False, collections.OrderedDict()), 0.1, 1e-05, None, 2, 1, False, ... ) ... ``` Now `python -m torch.utils.show_pickle bytecode.pkl` ``` ('constants', (0.1, 1e-05, None, 2, 1, False, 0, True, False, 1, 2, 3, ('tensor_jit_index', 4), ('tensor_jit_index', 3), ('tensor_jit_index', 2), 0.1, 1e-05, None, 2, 1, False, 0, 24, True, 58, ('tensor_jit_index', 0), 3, ('tensor_jit_index', 1), -1, ('tensor_jit_index', 12), ('tensor_jit_index', 11), ('tensor_jit_index', 10), ('tensor_jit_index', 9), ('tensor_jit_index', 8), ('tensor_jit_index', 7), ('tensor_jit_index', 6), 0.1, 1e-05, None, 2, 1, False, ) ... ``` ## Test 1. Build pytorch locally. `MACOSX_DEPLOYMENT_TARGET=10.9 CC=clang CXX=clang++ USE_CUDA=0 DEBUG=1 MAX_JOBS=16 python setup.py develop` 2. Run `python save_lite.py` ``` import torch # ~/Documents/pytorch/data/dog.jpg model = torch.hub.load('pytorch/vision:v0.6.0', 'shufflenet_v2_x1_0', pretrained=True) model.eval() # sample execution (requires torchvision) from PIL import Image from torchvision import transforms import pathlib import tempfile import torch.utils.mobile_optimizer input_image = Image.open('~/Documents/pytorch/data/dog.jpg') preprocess = transforms.Compose([ transforms.Resize(256), transforms.CenterCrop(224), transforms.ToTensor(), transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]), ]) input_tensor = preprocess(input_image) input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model # move the input and model to GPU for speed if available if torch.cuda.is_available(): input_batch = input_batch.to('cuda') model.to('cuda') with torch.no_grad(): output = model(input_batch) # Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes print(output[0]) # The output has unnormalized scores. To get probabilities, you can run a softmax on it. print(torch.nn.functional.softmax(output[0], dim=0)) traced = torch.jit.trace(model, input_batch) sum(p.numel() * p.element_size() for p in traced.parameters()) tf = pathlib.Path('~/Documents/pytorch/data/data/example_debug_map_with_tensorkey.ptl') torch.jit.save(traced, tf.name) print(pathlib.Path(tf.name).stat().st_size) traced._save_for_lite_interpreter(tf.name) print(pathlib.Path(tf.name).stat().st_size) print(tf.name) ``` 3. Run `python test_lite.py` ``` import torch from torch.jit.mobile import _load_for_lite_interpreter # sample execution (requires torchvision) from PIL import Image from torchvision import transforms input_image = Image.open('~/Documents/pytorch/data/dog.jpg') preprocess = transforms.Compose([ transforms.Resize(256), transforms.CenterCrop(224), transforms.ToTensor(), transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]), ]) input_tensor = preprocess(input_image) input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model reload_lite_model = _load_for_lite_interpreter('~/Documents/pytorch/experiment/example_debug_map_with_tensorkey.ptl') with torch.no_grad(): output_lite = reload_lite_model(input_batch) # Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes print(output_lite[0]) # The output has unnormalized scores. To get probabilities, you can run a softmax on it. print(torch.nn.functional.softmax(output_lite[0], dim=0)) ``` 4. Compare the result with pytorch in master and pytorch built locally with this change, and see the same output. 5. The model size was 16.1 MB and becomes 12.9 with this change. Differential Revision: [D25982807](https://our.internmc.facebook.com/intern/diff/D25982807) [ghstack-poisoned]
laurentdupin
pushed a commit
to laurentdupin/pytorch
that referenced
this pull request
Apr 24, 2026
Summary: Pull Request resolved: pytorch#49916 Test Plan: 1. Build pytorch locally. `MACOSX_DEPLOYMENT_TARGET=10.9 CC=clang CXX=clang++ USE_CUDA=0 DEBUG=1 MAX_JOBS=16 python setup.py develop` 2. Run `python save_lite.py` ``` import torch # ~/Documents/pytorch/data/dog.jpg model = torch.hub.load('pytorch/vision:v0.6.0', 'shufflenet_v2_x1_0', pretrained=True) model.eval() # sample execution (requires torchvision) from PIL import Image from torchvision import transforms import pathlib import tempfile import torch.utils.mobile_optimizer input_image = Image.open('~/Documents/pytorch/data/dog.jpg') preprocess = transforms.Compose([ transforms.Resize(256), transforms.CenterCrop(224), transforms.ToTensor(), transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]), ]) input_tensor = preprocess(input_image) input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model # move the input and model to GPU for speed if available if torch.cuda.is_available(): input_batch = input_batch.to('cuda') model.to('cuda') with torch.no_grad(): output = model(input_batch) # Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes print(output[0]) # The output has unnormalized scores. To get probabilities, you can run a softmax on it. print(torch.nn.functional.softmax(output[0], dim=0)) traced = torch.jit.trace(model, input_batch) sum(p.numel() * p.element_size() for p in traced.parameters()) tf = pathlib.Path('~/Documents/pytorch/data/data/example_debug_map_with_tensorkey.ptl') torch.jit.save(traced, tf.name) print(pathlib.Path(tf.name).stat().st_size) traced._save_for_lite_interpreter(tf.name) print(pathlib.Path(tf.name).stat().st_size) print(tf.name) ``` 3. Run `python test_lite.py` ``` import torch from torch.jit.mobile import _load_for_lite_interpreter # sample execution (requires torchvision) from PIL import Image from torchvision import transforms input_image = Image.open('~/Documents/pytorch/data/dog.jpg') preprocess = transforms.Compose([ transforms.Resize(256), transforms.CenterCrop(224), transforms.ToTensor(), transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]), ]) input_tensor = preprocess(input_image) input_batch = input_tensor.unsqueeze(0) # create a mini-batch as expected by the model reload_lite_model = _load_for_lite_interpreter('~/Documents/pytorch/experiment/example_debug_map_with_tensorkey.ptl') with torch.no_grad(): output_lite = reload_lite_model(input_batch) # Tensor of shape 1000, with confidence scores over Imagenet's 1000 classes print(output_lite[0]) # The output has unnormalized scores. To get probabilities, you can run a softmax on it. print(torch.nn.functional.softmax(output_lite[0], dim=0)) ``` 4. Compare the result with pytorch in master and pytorch built locally with this change, and see the same output. 5. The model size was 16.1 MB and becomes 12.9 with this change. Imported from OSS Reviewed By: kimishpatel, iseeyuan Differential Revision: D25731596 Pulled By: cccclai fbshipit-source-id: 9731ec1e0c1d5dc76cfa374d2ad3d5bb10990cf0
This file contains hidden or bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
Sign up for free
to join this conversation on GitHub.
Already have an account?
Sign in to comment
4 participants
Add this suggestion to a batch that can be applied as a single commit.This suggestion is invalid because no changes were made to the code.Suggestions cannot be applied while the pull request is closed.Suggestions cannot be applied while viewing a subset of changes.Only one suggestion per line can be applied in a batch.Add this suggestion to a batch that can be applied as a single commit.Applying suggestions on deleted lines is not supported.You must change the existing code in this line in order to create a valid suggestion.Outdated suggestions cannot be applied.This suggestion has been applied or marked resolved.Suggestions cannot be applied from pending reviews.Suggestions cannot be applied on multi-line comments.Suggestions cannot be applied while the pull request is queued to merge.Suggestion cannot be applied right now. Please check back later.
Summary
Jit will generate constant tensor value, and it locates in the constant folder after unzip model.ptl. Bytecode generated by lite interpreter also includes constant tensor, which are almost the same with the constant tensor value from jit. This pr reuses the constant tensor from jit. The implementation is:
export_module.cpp, store all constant tensor value from jit in anunordered_map constants_from_jit, where the tensor value use tensor string as a hash. When writing bytecode (writeByteCodefunction), the mapconstants_from_jitwill also be passed. If the constant in bytecode exist inconstants_from_jit, it will be replaced by a tuple in this format('tensor_jit_index', 4), where 4 is the index in tensor table from jit.import.cpp, it will also read fromconstantsfolder and loads the constant tensor. Then it scans the constants tensor from bytecode. If there exists tuple in this format('tensor_jit_index', 4)underconstantsfields, it will fetch the constant from the tensor table from jit and replace with it accordingly.Previous
python -m torch.utils.show_pickle bytecode.pklNow
python -m torch.utils.show_pickle bytecode.pklTest
MACOSX_DEPLOYMENT_TARGET=10.9 CC=clang CXX=clang++ USE_CUDA=0 DEBUG=1 MAX_JOBS=16 python setup.py developpython save_lite.pypython test_lite.pyStack from ghstack:
Differential Revision: D25731596
