TRACE-ZERO — Optimal Execution Simulator

A full-stack institutional-grade trading simulator that replays real market microstructure data and compares four liquidation strategies — Almgren-Chriss optimal execution, VWAP, TWAP, and market dump — measuring implementation shortfall, execution variance, and AC utility across a live animated Bloomberg Terminal UI.

What This Is

Most execution algorithm implementations are theoretical scripts that spit out a matplotlib graph. This one isn't.

TRACE-ZERO connects a market replay engine (real Binance L2 orderbook data) to a simulated matching engine that walks the full depth of book to compute exact multi-level slippage, applies permanent and temporary price impact as orders are filled, and models network execution latency. Four strategies run simultaneously against independent exchange instances. The result streams tick-by-tick over WebSocket to a Bloomberg Terminal-aesthetic UI built with TradingView's Lightweight Charts library.

The payoff: a live tear sheet that quantifies, in basis points, exactly how much the AC optimal trajectory saves over every industry benchmark — including VWAP, the actual standard desks use.

The Finance

Almgren-Chriss Optimal Liquidation (2000)

Given a position of $X$ shares to liquidate over horizon $T$ with $N$ child orders, the model solves for the trajectory ${x_j}$ minimising mean-variance execution cost:

$$\min_{{x_j}} \quad E[C] + \lambda \cdot \text{Var}[C]$$

Where:

Permanent impact — each trade shifts the midprice permanently: $g(v) = \gamma \cdot v$
Temporary impact — per-trade spread + depth cost: $h(v) = \varepsilon \cdot \text{sgn}(v) + \eta \cdot v/\tau$
$\lambda$ — risk aversion (controls the speed/risk tradeoff: $\lambda \to 0$ approaches TWAP, $\lambda \to \infty$ approaches immediate dump)

The closed-form optimal schedule uses a hyperbolic sine trajectory:

$$\tilde{x}_j = X \cdot \frac{2\sinh!\left(\tfrac{1}{2}\kappa\tau\right)}{\sinh(\kappa T)} \cdot \cosh!\left(\kappa!\left(T - \left(j - \tfrac{1}{2}\right)\tau\right)\right)$$

Where $\kappa$ is derived from the model parameters and encodes the "urgency" of execution.

Calibration from Real L2 Data

AC parameters are derived directly from the replay feed and updated dynamically:

Parameter	How it's derived
$\sigma^2$	Rolling variance of log mid-price returns, scaled to interval $\tau = T/N$; recalibrated every `calibration_window` ticks
$\varepsilon$	Rolling median half-spread: `median((ask - bid) / 2)` over the calibration window
$\gamma$, $\eta$	Standard AC scaling from spread and daily volume estimate — exposed as UI overrides
$\kappa$	Recomputed from updated $\sigma^2$ and $\varepsilon$ on each recalibration cycle (heteroscedasticity correction)

L2 Walk-the-Book Slippage

When L2 depth data is available, the matching engine replaces the analytical temporary impact formula with exact multi-level slippage:

$$\bar{p}(q) = \frac{\displaystyle\sum_{\ell}, p_\ell \cdot f_\ell}{\displaystyle\sum_{\ell}, f_\ell}, \qquad f_\ell = \min!\left(q_\ell,; q - \sum_{j < \ell} f_j\right)$$

Orders consume resting bid-side volume level-by-level. If the order size exceeds total resting depth, the remainder fills at the worst available price. This models real institutional execution far more accurately than the flat-book assumption.

VWAP Strategy

The VWAP benchmark executes proportional to a stylized intraday volume profile:

$$w(t) = \text{base} + \text{amplitude} \cdot (2t - 1)^2, \quad t \in [0,1]$$

This U-shaped curve (high volume at open and close, lower mid-session) mirrors crypto market microstructure. Child order sizes are weighted by $w(t)$ normalized to sum to total shares — the actual methodology used by institutional execution desks.

Implementation Shortfall

Each strategy's execution quality is measured in basis points:

$$\text{IS (bps)} = \frac{P_{\text{arrival}} - \text{VWAP}_{\text{fills}}}{P_{\text{arrival}}} \times 10{,}000$$

A lower shortfall = more value extracted from the liquidation.

Architecture

flowchart TB
    subgraph DATA["Data Layer"]
        direction LR
        BINANCE["Binance WS Stream"]
        PARQUET[".parquet — depth20 + L1"]
        SYNTHETIC["Synthetic GBM Book"]
        BINANCE -->|"collector.py capture"| PARQUET
        PARQUET -->|"loader.py Parquet-first"| EVENTS
        SYNTHETIC -->|"seed=42 fallback"| EVENTS
        EVENTS(["events: list[dict]<br/>bid/ask/mid/levels<br/>timestamp_ms"])
    end

    subgraph BACKEND["FastAPI Backend  :8000"]
        direction TB
        EVENTS --> RUNNER

        subgraph RUNNER["Simulation Runner"]
            direction TB
            CAL["calibrate_from_replay()<br/>σ², ε → γ, η, κ"]
            ROLLING["Rolling Recal<br/>every N ticks"]
            CAL --> ROLLING

            subgraph EXCHANGES["4 Independent Exchange Instances"]
                direction LR
                EA["Exchange A<br/>SimulatedBook"]
                EB["Exchange B<br/>SimulatedBook"]
                EC["Exchange C<br/>SimulatedBook"]
                ED["Exchange D<br/>SimulatedBook"]
            end

            DUMP["DumpStrategy<br/>100% @ t=0"]
            TWAP["TWAPStrategy<br/>N equal slices"]
            VWAP["VWAPStrategy<br/>U-curve weighted"]
            AC["ACOptimalStrategy<br/>sinh trajectory"]

            DUMP --> EA
            TWAP --> EB
            VWAP --> EC
            AC --> ED

            ROLLING -->|"ACConfig"| AC
            ROLLING -->|"perm impact γ"| EA & EB & EC & ED

            EA -->|"walk_book(qty)<br/>slippage_bps"| FILLS
            EB -->|"walk_book(qty)<br/>slippage_bps"| FILLS
            EC -->|"walk_book(qty)<br/>slippage_bps"| FILLS
            ED -->|"walk_book(qty)<br/>slippage_bps"| FILLS
            FILLS(["Fill: price<br/>qty, slippage_bps<br/>perm_impact"])
        end

        THROTTLE["WS Throttle<br/>50ms default"]
        RUNNER -->|"every step"| THROTTLE
        THROTTLE -->|"snapshot msg"| WS_EP
        RUNNER -->|"on complete"| WS_EP
        WS_EP["WebSocket<br/>/simulation/{id}/stream"]

        REST["/simulation/run<br/>POST → sim_id"]
    end

    subgraph FRONTEND["Next.js Frontend  :3000"]
        direction TB
        HOOK["useSimulation()<br/>WS + state"]
        WS_EP -->|"snapshot / complete<br/>JSON frames"| HOOK
        REST -->|"sim_id"| HOOK

        subgraph CHARTS["Lightweight Charts (WebGL)"]
            PC["PriceChart<br/>mid / bid / ask"]
            TC["TrajectoryChart<br/>shares remaining × 4"]
            CC["CostChart<br/>cumul. IS bps × 4"]
        end

        HOOK --> PC & TC & CC
        HOOK --> BLOTTER["OrderBlotter<br/>fills table"]
        HOOK --> TEARSHEET["TearSheet<br/>IS · VAR · UTIL<br/>AC savings vs DUMP/TWAP"]

        FORM["SimulationForm<br/>symbol · shares · T · N<br/>λ · latency · cal window<br/>daily vol"] -->|"POST"| REST
    end

    classDef backend fill:#0d1117,stroke:#30363d,color:#e6edf3
    classDef frontend fill:#0d1117,stroke:#30363d,color:#e6edf3
    classDef data fill:#0d1117,stroke:#30363d,color:#e6edf3
    classDef highlight fill:#001800,stroke:#238636,color:#3fb950
    classDef strategy fill:#161b22,stroke:#30363d,color:#8b949e

    class AC highlight
    class DUMP,TWAP,VWAP strategy

Project Structure

trace-zero/
├── backend/
│   ├── main.py                         # FastAPI app, CORS
│   ├── models/
│   │   └── almgren_chriss.py           # ACConfig + AlmgrenChriss + recalibrate()
│   ├── engine/
│   │   ├── order.py                    # Order / Fill dataclasses
│   │   ├── book.py                     # SimulatedBook: L2 depth + walk_book()
│   │   └── exchange.py                 # SimulatedExchange: walk-book fills + latency queue
│   ├── strategies/
│   │   ├── base.py                     # Abstract Strategy + TradeSlice
│   │   ├── dump.py                     # 100% at t=0
│   │   ├── twap.py                     # N equal slices over T
│   │   ├── vwap.py                     # U-shaped volume profile schedule
│   │   └── ac_optimal.py               # AC hyperbolic sine schedule
│   ├── simulation/
│   │   ├── config.py                   # SimulationConfig (incl. latency_ms, cal_window)
│   │   ├── runner.py                   # Orchestrator: rolling cal + throttle + latency
│   │   └── results.py                  # StrategyResult + SimulationResult (4 strategies)
│   ├── market_replay/
│   │   ├── collector.py                # Binance combined stream (bookTicker + depth20)
│   │   ├── normalizer.py               # L1 + L2 event normalization
│   │   ├── logger.py                   # Parquet (Polars/Snappy) + JSONL fallback writer
│   │   ├── replay.py                   # Generator-based replay
│   │   └── loader.py                   # Parquet-first loader + dual-format metadata
│   └── api/
│       ├── routes.py                   # REST endpoints
│       └── ws.py                       # WebSocket streaming
├── frontend/
│   └── src/
│       ├── app/
│       ├── components/
│       │   ├── Terminal.tsx            # Root grid layout
│       │   ├── TopBar.tsx              # Brand bar + live clock + status
│       │   ├── SimulationForm.tsx      # Parameters incl. Latency + Cal Window
│       │   ├── PriceChart.tsx          # Mid-price (Lightweight Charts)
│       │   ├── TrajectoryChart.tsx     # Shares remaining — 4 strategies
│       │   ├── CostChart.tsx           # Cumulative shortfall — 4 strategies
│       │   ├── TearSheet.tsx           # 4-column Bloomberg comparison table
│       │   ├── OrderBlotter.tsx        # Scrolling child order fills
│       │   └── Panel.tsx               # Reusable panel wrapper
│       └── hooks/
│           └── useSimulation.ts        # WS connection + React state (vwap added)
├── data/                               # Captured .parquet files (git-ignored)
├── scripts/
│   └── capture_data.py                 # CLI capture wrapper
├── pyproject.toml
└── OptimalPath(withoutMarketMovements).py   # Original reference (kept for diff)

Getting Started

Prerequisites

Python ≥ 3.11
Node.js ≥ 18

1. Install backend

git clone https://github.com/Dharshan2004/trace-zero.git
cd trace-zero
pip install -e .

Dependencies include polars and pyarrow for Parquet support — install them if not pulled automatically:

pip install polars pyarrow

2. Start the API server

uvicorn backend.main:app --reload --port 8000

No data file required — if data/ is empty the runner generates a synthetic BTC price path (geometric random walk, ~$97k mid, 3-level synthetic L2 book) so you can run immediately.

3. Start the frontend

cd frontend
npm install
npm run dev

Open http://localhost:3000.

4. Run your first simulation

The form is pre-filled with sensible defaults. Hit GO and watch:

Price chart — mid-price from the replay feed
Trajectory chart — Dump drops to zero instantly (red), TWAP steps linearly (yellow), VWAP follows volume curve (purple), AC traces a concave curve (green)
Shortfall chart — cumulative cost in bps diverges over time; AC should finish lowest
Tear sheet — final VWAP price, IS shortfall, trajectory variance, and utility for all four strategies with best (green) / worst (red) highlighting

Capturing Real Market Data

L2 capture (recommended)

Subscribes to the Binance combined stream (bookTicker + depth20@100ms) and writes a Parquet file with full depth data:

# Via the API (background task)
curl -X POST http://localhost:8000/api/capture \
  -H "Content-Type: application/json" \
  -d '{"symbol": "BTCUSDT", "duration_seconds": 60, "use_l2": true}'

# Output: data/BTCUSDT_60s.parquet

L1 legacy capture

python scripts/capture_data.py BTCUSDT 60
# Output: data/BTCUSDT_60s.jsonl (still supported)

Files land in data/ (git-ignored). The UI lists available files automatically via GET /api/symbols. Parquet files take priority over JSONL when both exist for the same symbol.

Using Real Data Effectively

IS ordering in the tear sheet is market-condition dependent when real data is loaded:

Market condition during capture	DUMP IS	TWAP/VWAP/AC IS	Why
Price falls	Low (best)	High	DUMP sold at peak; later fills are cheaper
Price rises	High (worst)	Lower	DUMP sold at trough; TWAP/AC caught the rally
Price flat	High (worst)	Lower	Only market impact matters; single large dump pays more

For a reliable demo with the expected ordering (DUMP worst, AC best), capture during a low-volatility, flat-to-slightly-rising window — typically early morning UTC or weekends. Avoid capturing during strong directional moves or news events.

Verify a capture before presenting:

python3 - << 'EOF'
import json

events = []
with open('data/BTCUSDT_60s.jsonl') as f:
    for line in f:
        if line.strip():
            events.append(json.loads(line))

first_mid = (events[0]['bid'] + events[0]['ask']) / 2
last_mid  = (events[-1]['bid'] + events[-1]['ask']) / 2
drift_bps = (last_mid - first_mid) / first_mid * 10000
depth     = sum(float(l[1]) for l in events[0].get('bid_levels', []))

print(f"Events : {len(events)}")
print(f"Drift  : {drift_bps:+.1f} bps  ({'FLAT ✓' if abs(drift_bps) < 5 else 'RISING ✓' if drift_bps > 0 else 'FALLING ✗ — recapture'})")
print(f"Depth  : {depth:.3f} BTC/side at tick 0")
EOF

Green light: drift between −5 bps and +15 bps. Recapture if drift < −5 bps (falling market means DUMP will show lowest IS).

Recommended parameters with real data:

Parameter	Value	Why
`total_shares`	`1.0`	Real BTC book has ~1–2 BTC total depth per side; larger orders exhaust it and all strategies get identical worst-level fills
`liquidation_time`	`60`	Matches a 60s capture
`num_trades`	`20`	~3s between child orders
`daily_volume_estimate`	`1000000000`	1B USD default; increasing this shrinks γ and η, reducing impact differences

Guaranteed ordering (synthetic mode): If you need deterministic DUMP-worst ordering regardless of market conditions, delete the data file — the simulator falls back to a seeded geometric random walk with a flat price path where only market impact matters.

rm data/BTCUSDT_60s.jsonl   # or .parquet
# Restart backend — simulator now runs in synthetic mode

Simulation Parameters

Parameter	Default	Description
`symbol`	`BTCUSDT`	Market symbol label
`total_shares`	`1.0`	Total shares/contracts to liquidate
`liquidation_time`	`60`	Liquidation horizon in minutes
`num_trades`	`20`	Number of discrete child orders
`risk_aversion`	`1e-6`	AC lambda — higher = more front-loaded
`latency_ms`	`0`	Network round-trip latency in ms. Orders are evaluated against the book state `latency_ms` later — models execution risk
`calibration_window`	`100`	Rolling window size for volatility/spread recalibration. `0` = static (single-pass calibration)
`gamma_override`	`null`	Override calibrated permanent impact coefficient
`eta_override`	`null`	Override calibrated temporary impact coefficient

API Reference

Method	Endpoint	Description
`GET`	`/api/symbols`	List available data files (.parquet + .jsonl)
`GET`	`/api/symbols/{symbol}/info`	Event count, time range, price range, format
`POST`	`/api/simulation/run`	Start simulation, returns `{"sim_id": "..."}`
`WS`	`/api/simulation/{sim_id}/stream`	Stream throttled snapshots
`POST`	`/api/capture`	Trigger live Binance L2 capture

POST /api/simulation/run

{
  "symbol": "BTCUSDT",
  "total_shares": 1.0,
  "liquidation_time": 60,
  "num_trades": 20,
  "risk_aversion": 1e-6,
  "latency_ms": 30.0,
  "calibration_window": 100,
  "ui_throttle_ms": 50,
  "gamma_override": null,
  "eta_override": null
}

WebSocket snapshot message

{
  "type": "snapshot",
  "step": 5,
  "total_steps": 20,
  "mid_price": 97432.10,
  "timestamp_ms": 1709654400000,
  "strategies": {
    "dump": { "shares_remaining": 0.0,  "avg_price": 97380.0, "cumulative_cost_bps": 52.1 },
    "twap": { "shares_remaining": 0.75, "avg_price": 97445.0, "cumulative_cost_bps": 18.3 },
    "vwap": { "shares_remaining": 0.71, "avg_price": 97447.0, "cumulative_cost_bps": 14.6 },
    "ac":   { "shares_remaining": 0.82, "avg_price": 97448.0, "cumulative_cost_bps": 8.7  }
  }
}

Final message type is "complete" with the full SimulationResult.

Verification Checklist

Scenario	Expected behaviour
λ → 0	AC schedule converges to TWAP (flat trade list)
λ → ∞	AC schedule converges to Dump (one large first trade)
All shares sold	Each strategy liquidates 100% by final step
Trajectory shapes	Dump: vertical drop at t=0. TWAP: linear staircase. VWAP: U-weighted staircase. AC: smooth concave curve
Shortfall ordering	For moderate λ: IS(dump) > IS(twap) > IS(vwap) > IS(ac)
Latency effect	With `latency_ms=30`, fills execute against a book 30ms stale — IS should increase modestly
L2 vs L1	With depth data, large orders should show higher IS than L1 (flat-book) mode due to level-walking
Permanent impact isolation	Changing λ should not affect Dump or TWAP results
Rolling calibration	With volatile data, kappa should drift across steps as sigma2 updates

Tech Stack

Backend

FastAPI + uvicorn — async REST and WebSocket server
NumPy — all AC model mathematics
Polars + PyArrow — columnar Parquet I/O (~80% smaller than JSONL)
websockets — Binance live L2 data capture
Pure Python dataclasses throughout — no database, no ORM

Frontend

Next.js 15 (App Router, SWC compiler)
Lightweight Charts (TradingView) — WebGL-accelerated financial charts
Tailwind CSS — utility styling with custom Bloomberg color theme
JetBrains Mono — monospace terminal font

Reference

Almgren, R. & Chriss, N. (2000). Optimal execution of portfolio transactions. Journal of Risk, 3(2), 5–39.
Almgren, R. (2003). Optimal execution with nonlinear impact functions and trading-enhanced risk. Applied Mathematical Finance, 10(1), 1–18.

Built For

This project was built as part of the ProjectHub Mentorship Program 25/26 — a project-based initiative by the NTU School of Computer Science and Data Science (CCDS) Student Society that connects students with mentors in computing and data science to build real-world projects and gain industry exposure.

Hands-on, project-focused mentorship · Small mentor–mentee groups · Technical growth and career exploration

Team

Name	GitHub	Role
Kannan Priyadharshan	@Dharshan2004	Lead Engineer
Arya Vatsa	@AryaVatsa	Engineer
Poh Shi Sien	@PohShiSien	Engineer

License

MIT — see LICENSE

Name		Name	Last commit message	Last commit date
Latest commit History 6 Commits
backend		backend
data		data
frontend		frontend
scripts		scripts
.env.example		.env.example
.gitignore		.gitignore
LICENSE		LICENSE
OptimalPath(withoutMarketMovements).py		OptimalPath(withoutMarketMovements).py
Procfile		Procfile
README.md		README.md
pyproject.toml		pyproject.toml

Folders and files

Latest commit

History

Repository files navigation

TRACE-ZERO — Optimal Execution Simulator

What This Is

The Finance

Almgren-Chriss Optimal Liquidation (2000)

Calibration from Real L2 Data

L2 Walk-the-Book Slippage

VWAP Strategy

Implementation Shortfall

Architecture

Project Structure

Getting Started

Prerequisites

1. Install backend

2. Start the API server

3. Start the frontend

4. Run your first simulation

Capturing Real Market Data

L2 capture (recommended)

L1 legacy capture

Using Real Data Effectively

Simulation Parameters

API Reference

POST /api/simulation/run

WebSocket snapshot message

Verification Checklist

Tech Stack

Reference

Built For

Team

License

About

Resources

License

Uh oh!

Stars

Watchers

Forks

Releases

Packages 0

Uh oh!

Contributors

Uh oh!

Languages

Packages
